1.Lamp Source：350W；
2.Input Voltage(V): AC100V-240V/50-60Hz
3.Total Power：500W；
4.Color wheel：14 colors + open ；
5.Gobo wheel：14 fixed gobo,9 glass rotation gobo.
6.Prism：rotate 8 prism and 6 row prism；
7.Dimmer：0-100% dimmer；
8.Beam angel could adjust ,wide range ；
9.Strobe：Support mechanical stroboscopic and adjustable speed stroboscopic effect, and support stroboscopic macro function；
10.Lens group optical system, electric focusing, beam angle 3.8 ° - 45 °, linearly adjustable;
11.Photoelectric reset system is adopted, which can automatically retrieve and reset in case of accidental misoperation；
12.Pan:540°， 8Bit/16Bit；
13.Tilt: 270°，8Bit/16Bit；
14.Overheat protection；
15.Control Mode：DMX512/Master-Slave/Auto；
16.IP：IP20；
1.Lamp Source：350W；
2.Input Voltage(V): AC100V-240V/50-60Hz
3.Total Power：500W；
4.Color wheel：14 colors + open ；
5.Gobo wheel：14 fixed gobo,9 glass rotation gobo.
6.Prism：rotate 8 prism and 6 row prism；
7.Dimmer：0-100% dimmer；
8.Beam angel could adjust ,wide range ；
9.Strobe：Support mechanical stroboscopic and adjustable speed stroboscopic effect, and support stroboscopic macro function；
10.Lens group optical system, electric focusing, beam angle 3.8 ° - 45 °, linearly adjustable;
11.Photoelectric reset system is adopted, which can automatically retrieve and reset in case of accidental misoperation；
12.Pan:540°， 8Bit/16Bit；
13.Tilt: 270°，8Bit/16Bit；
14.Overheat protection；
15.Control Mode：DMX512/Master-Slave/Auto；
16.IP：IP20；
None
ROTATE GOBO WHEEL
STATIC GOBO WHEEL
COLOUR WHEEL
DMX Channel
Library
User manual
